FUNCTIONAL TESTS Chapter 4
4 - 15
4.3 AS50 FUNCTIONAL TEST DATA SHEET
1 of 2
Pump Serial Number _________________________
Indicate PASS or FAIL, as appropriate, upon completion of each operation.
Describe any failures in Comment section and seek appropriate servicing.
4.2.4 Visual Inspection................................................................................................................. ( ) P ( ) F
4.2.5 Charging Circuit, step 2
...................................................................................................... ( ) P ( ) F
4.2.6 Power On Self Test (POST)................................................................................................ ( ) P ( ) F
4.2.7 LCD and step 1
(all nine LEDs momentarily turn ON)...................................... ( ) P ( ) F
LED Check step 2
(all LCD segments appear as shown).................................... ( ) P ( ) F
4.2.8 Keypad Check, step 1 (Repeated beeps verified for START & STOP keys).............. ( ) P ( ) F
step 2
(Short beep verified for all keys except arrow keys)............... ( ) P ( ) F
step 3
(No response detected for simultaneously keypress)............ ( ) P ( ) F
step 4
(One beep detected for all keys except arrows,
START & STOP) ................................................................... ( ) P ( ) F
step 5
(No response detected for second keypress) ........................ ( ) P ( ) F
4.2.9 Range of Motion, step 1
(Plunger Driver & Barrel Clamp travel freely)......................... ( ) P ( ) F
step 2
(Plunger Driver seats and locks properly and does not slip) ( ) P ( ) F
step 3
(Both barrel clamp release levers operate properly).............. ( ) P ( ) F
step 4
(Tab Lock opens and closes properly)................................... ( ) P ( ) F
4.2.10 Pump Operational Tests
4.2.10.1 Occlusion PSI step 5 (Pump displays RUNNING for approximately 2 seconds)...... ( ) P ( ) F
Test step 7 (LINE OCCLUDED is displayed, ALERT & STANDBY LEDs
flash, and pump beeps continuously ).................................. ( ) P ( ) F
step 9 (optional)
Specification = [12.0 psi < pressure reading < 20.0 psi]
Pressure reading _________________________ ............. ( ) P ( ) F
4.2.10.2 Near End step 4 (Pump displays RUNNING for approximately 2 seconds &
Alarm Test RUN LEDs flash in descending order).................................. ( ) P ( ) F
step 5 (Pump displays < 10 MIN VOL LIMIT
message with 5 beeps) ........................................................ ( ) P ( ) F
step 6 (VOLUME LIMIT is displayed, ALERT & STANDBY LEDs
flash, and pump beeps continuously)................................... ( ) P ( ) F
4.2.10.3 Accuracy step 3 (Start Volume) _____________________
Test step 6 (Stop Volume) ____________________
Specification = [48.5 cc < volume delivered < 51.5 cc]
Volume delivered _________________________.............. ( ) P ( ) F
4.2.10.4 Shutdown Alarm step 5 (Pump continuously alarms for a minimum of 3 minutes) ...... ( ) P ( ) F
4.2.10.5 Fuse Fail. Alarm step 5
(Fuse Failure display, Battery & System LEDs, beeps) ......... ( ) P ( ) F
4.2.11 Calibration Review Section
4.2.11.2 Plunger Drive step 2
(BATTERY, STANDBY, & LOCK LEDs turn on)................... ( ) P ( ) F
Position Review
step 3
Specification = [2.792 < inches value < 2 .804]
Value observed _________________________ ................ ( ) P ( ) F
step 4
(BATTERY, STANDBY, & LOCK LEDs turn on)................... ( ) P ( ) F
step 5 Specification = [0.666 < inches value < 0.678]
Value observed _________________________ ............... ( ) P ( ) F
This page may be reproduced.
4.3 AS50 FUNCTIONAL TEST DATA SHEET
2 of 2
