Chapter 9 CONFIGURATION REPLICATION
9 - 2
spaces provided on the Data Sheet at the end of this Chapter. The S/W Version is
displayed on line 1. The Configuration Version is displayed on the left side of line 2
and the Configuration Checksum is displayed on the right side of line 2. If you need to
review these numbers again, repeat steps 8-10.
11. Turn off the source pump.
12. Verify accuracy of configuration with appropriate clinical personnel prior to proceeding.
9.2.2 Setting up the Destination Pump
1. Ensure that the destination pump is turned off.
2. Remove the DB9 port’s cover and connect the other end of the replication cable to this
port. Secure the cable with the attached thumbscrews.
3. Turn on the destination pump and allow the pump to go through its POST. DO NOT
press any keys until told to do so.
4. After SELECT LIBRARY or SELECT MODE is displayed, press “9805”. There will be
a momentary Date and Time display and a momentary S/W Version display.
5. When the CONFIG LIBRARY prompt appears on the display, press confirm to accept
the Y response.
6. At the ENTER CODE prompt, enter the library access code.
7. At the SELECT FUNCTION prompt, press ▼ until RECEIVE is displayed.
8. Press CONFIRM. The pump will display PRESS START TO RECEIVE OR CLR TO
QUIT. DO NOT press any key until told to do so.
9.2.3 Replication Procedure
1. Turn on the source pump. DO NOT press any key on the source pump. If a key is
inadvertently pressed, turn off the source pump and repeat this step.
2. After the source pump displays SELECT LIBRARY, press START on the destination
pump.
3. The destination pump will display UPDATING, while the source pump is displaying
SENDING.
