baxter Auto Syringe AS50 Service Manual

APPENDIX C REPAIR PARTS
C - 6
Table C-E Cover Assembly
Figure
ID Number
Part Description Baxter® Part
Number
Quantity
per
Assembly
E-1
Cover/Window Assembly AAS5001522RP 1
E-2 2-56 x 9/16" Socket Head Cap Screw S025609600 4
E-3 Plunger Warning Decal BAS5001018 1
E-4 Cover Screw BAS4001653 1
E-5 Digital/LCD PCB Assembly DAS5001353 1
E-6 Electronic Chassis DAS4001410 1
E-7 Analog PCB Retainer DAS4001409 1
E-8 Analog PCB Assembly DAS5001352 1
E-9 Keypad Assembly AAS5001523RP 1
E-10 Conductive Gasket (cut gasket material into 8 BAS4001486 1
pieces as listed below:)
Quantity Length Used with PCB Assy:
2 8 3/4" Digital/LCD
2 2 11/16" Digital/LCD
2 8 3/4" Analog
2 1 5/8" Analog
E-11 Digital PCB Retainer DAS4001408 1
E-12 Charger Port Decal BAS5001013 1
