baxter Auto Syringe AS50 Service Manual

APPENDIX C REPAIR PARTS
C - 8
Table C-F Case Assembly
Figure
ID Number
Part Description Baxter® Part
Number
Quantity per
Assembly
F-1 Case/IV Pole Loop/Drive Assembly AAS5001531R
P
1
F-2 Battery Warning Decal BAS5001011 1
F-3 10-32 x 3/8" Hex Insert A100301439 1
F-4 RS232 Connector Cover BAS5001475 1
F-5 4-40 x 3/16" Button Head Screw S044003613 2
F-6 Product Code Label BAS5001016 1
F-7 Switch Bezel With Markings BAS5001603 1
F-8 Instruction Decal BAS5001015 1
F-9 RS232 Gasket BAS5001425 1
F-10 Connector Spacer BAS4001622 1
F-11 I/O Board Assembly DAS5001350 1
F-12 Switch Gasket BAS4001015 1
F-13 Switch Retainer Spring BAS4001602 1
F-14 2-56 x 1/8" Socket Head Cap Screw S025602600 2
F-15 2-56 x 1/4" Pan Head Screw S025604652 8
F-16 .036" Stainless Steel Washer A100301429 1
F-17 10-32 x 1/4" Pan Head Screw S103204613 1
F-18 Overlay Decal BAS4000046 1
