baxter Auto Syringe AS50 Service Manual

TROUBLESHOOTING AND REPAIR Chapter 6
6 - 3
TABLE 6-1
Symptom Possible Cause Solution
into unit and observe the
charge LED. Charger
and/or I/O board may need
replacement.
Damaged pins in charger
connector
Ensure that charger
connector pins are seated
properly. If necessary,
replace I/O board.
Part or all of keypad is
inoperable
Malfunctioning keypad Perform Functional Test in
Chapter 4. If pump fails,
replace keypad assembly.
Premature ATTACH
CHARGER alert or
premature BAD BATTERY
alarm
Low battery Run Battery Life Check in
Chapter 4. Replace battery
or recharge unit for a
minimum of 16 hours and
verify battery operation.
Damaged charger or charger
connector
Replace charger or I/O
board.
Battery worn out Replace battery (battery
should be replaced every 16
months).
Incorrect syringe size is
recognized or SIZE
MISMATCH errors
Improperly loaded syringe Reload syringe.
Wrong syringe manufacturer Verify correct manufacturer
has been programmed.
Pump out of calibration Check calibration and re-
calibrate, if necessary.
Contaminated barrel clamp Perform service cleaning
(see Chapter 5).
Malfunctioning barrel clamp
and/or barrel clamp zebra
strip
Replace barrel clamp and/or
barrel clamp zebra strip and
recalibrate.
Worn, frayed or damaged
barrel clamp zebra strip
Replace barrel clamp zebra
strip and recalibrate.
