Chapter 2 Recommended Installation Sequence Checklist
Main Checklist
Item
Installation Task
Optional
Components
Chapter Name
Chapter
Number(s)
5
INSTALL SIDE WHEEL HUB ASSEMBLIES
5.1
Confirm Driver Side Hub is on the Driver Side
Side Wheel Hub Assemblies
7
5.2
Confirm Passenger Side Hub is on the Passenger Side
Side Wheel Hub Assemblies
7
6
INSTALL SMART SPRAY ASSEMBLIES
6.1
Mount Driver Side Smart Spray
Yes
Smart Spray Assemblies
8
6.2
Mount Passenger Side Smart Spray
Yes
Smart Spray Assemblies
8
6.3
Connect Water Feed Manifolds to Smart Spray
Manifolds
Yes
Smart Spray Assemblies
8
6.4
Connect CTA Airlines (1/4” Clear) to Smart Spray Tees
Yes
Smart Spray Assemblies
8
6.5
Connect CTA Airlines (1/4” Purple) to Smart Spray
Foam Generators
Yes
Smart Spray Assemblies
8
6.6
Connect Airlines to Smart Spray Cylinders
Yes
Smart Spray Assemblies
8
6.7
Connect LED Cables to Smart Spray LEDs
Yes
Smart Spray Assemblies
8
7
MOUNT FLOOR ITEMS IN PROPER BAY LOCATION
7.1
Mount Entrance Photo-Eyes
Photo-Eyes
9
7.2
Mount Activation set of Photo-Eyes
Photo-Eyes
9
7.3
Mount Entrance Door Control Photo-Eyes
Yes
Photo-Eyes
9
7.4
Mount Exit Door Control Photo-Eyes
Yes
Photo-Eyes
9
7.5
Mount Undercarriage Assembly
Yes
Undercarriage Option
10
7.6
Mount Bug Spray Assembly
Yes
TBD
TBD
8
MOUNT ENTRY SYSTEM/SIGNS
8.1
Install Wait-Go Sign
Yes
Signage Option
17
8.2
Install Navigational/Wash Pass Sign
Yes
Signage Option
17
8.3
Install Point of Entry System/POS in store
Not Supplied by Belanger®
NA
9
ERECT DRYER FRAME AND MOUNT HOUSINGS
9.1
Install per Dryer Manual
Yes
See Dryer Manual
NA
10
ELECTRICIAN TO BEGIN INSTALL TO/FROM PANELS
10.1
Electrical Terminations made at Building Panel
Electrical & Schematic Drawings
4
10.2
Electrical Terminations made at Carriage Panel
Electrical & Schematic Drawings
4
10.3
Electrical Terminations made from ICS to Building
Panel
Injection Chemical System (ICS) &
Schematic Drawings
12
10.4
Electrical Terminations made at HMI Panel
Electrical & Schematic Drawings
4
10.5
Electrical Terminations made from Junction Box to
Carriage Panel
Yes
Electrical & Schematic Drawings
4
10.6
Electrical Terminations made at Photo-Eyes
Photo-Eyes & Schematic Drawings
9
10.7
Electrical Terminations made at Entry System/POS
Not Supplied by Belanger®
NA
10.8
Electrical Terminations made at ALL E-STOPS
Not Supplied by Belanger®
NA
10.9
Electrical Terminations made at Dryer Panel
Yes
Dryer Manual & Schematic Drawing
NA
10.10
Electrical Terminations from Dryer Panel to Dryer
Motors
Yes
Dryer Manual and Schematic
Drawings
NA
10.11
Electrical Terminations made at Navigation Signs
Yes
Signage Option & Schematic Draw.
17
10.12
Electrical Terminations made from High Pressure
Pumps to Disconnect Panel
Yes
High Pressure Pump Assembly &
Schematic Drawings
13
10.13
Electrical Terminations made from High Pressure
Pump Valves to Building Panel
Yes
High Pressure Pump Assembly &
Schematic Drawings
13
10.14
Electrical Terminations made at Spot Free Rinse (RO)
Unit
Yes
Spot Free Rinse (RO) Option &
Schematic Drawings
16
