Chapter 2 Recommended Installation Sequence Checklist
Main Checklist
Item
Installation Task
Optional
Components
Chapter Name
Chapter
Number(s)
11
INSTALL PLUMBING FROM MAIN WATER LINE
11.1
Install Plumbing to ICS
Injection Chemical System(ICS)
12
11.2
Install Plumbing to High Pressure Pump Valves then to
Pumps
Yes
High Pressure Pump Assembly
13
11.3
Install Plumbing to CTA MixStir® Tank
Yes
MixStir® for Chem. Tire Applic.
14
11.4
Install Plumbing to Bug Spray MixStir® Tank
Yes
TBD
TBD
11.5
Install Plumbing to Spot Free Rinse (RO) Unit
Yes
Spot Free Rinse (RO) Option
16
11.6
Install Plumbing to Water Softener Unit
Yes
Water Softener Option
15
11.7
Install Plumbing from Utility Manifold/Bulkhead Assembly
to ICS
Getting Started & Injection
Chemical System (ICS)
5 & 12
11.8
Install Plumbing from Utility Manifold/Bulkhead Assembly
to High Pressure Pump Assembly
Yes
Getting Started & High-
Pressure Pump Assembly
5 & 13
11.9
Install Plumbing from Utility Manifold/Bulkhead Assembly
to CTA MixStir® Tank
Yes
Getting Started & MixStir® for
Chemical Tire Application(CTA)
5 & 14
11.10
Install Plumbing from Utility Manifold/Bulkhead Assembly
to Spot Free Rinse (RO) Unit
Yes
Getting Started & Spot Free
Rinse (RO) Option
5 & 16
11.11
Install Plumbing from Bug Spray MixStir® Tank to Bug
Spray Unit
Yes
TBD
TBD
11.12
Install Plumbing from ICS to Undercarriage Unit
Yes
Undercarriage Option
10
12
INSTALL PLUMBING FROM AIR COMPRESSOR
12.1
Install Plumbing to Main System Air Panel
Getting Started & Air Panels
5-1 & 11
12.2
Install Plumbing from Utility Manifold/Bulkhead Assembly
to Main System Air Panel
Air Panels
11
12.3
Install Plumbing to Single Foam Air Panel
Yes
Air Panels
11
12.4
Install Plumbing from Utility Manifold/Bulkhead Assembly
to Single Foam Air Panel
Yes
Air Panels
11
12.5
Install Plumbing to Triple Foam Air Panel
Yes
Air Panels
11
12.6
Install Plumbing from Utility Manifold/Bulkhead Assembly
to Triple Foam Air Panel
Yes
Air Panels
11
12.7
Install Plumbing to CTA MixStir® Tank
Yes
MixStir® for Chem. Tire Applic.
14
12.8
Install Plumbing to Bug Spray MixStir® Tank
Yes
TBD
TBD
13
WHEN INSTALLATION IS FINALIZED
13.1
Complete the Startup Procedure
Initial Startup
19
13.2
Prep Water Softener
Yes
Initial Startup
19
13.3
Prep Spot Free Rinse (RO) Unit
Yes
Initial Startup
19
13.4
Dryer Adjustments
Yes
See Dryer Manual
NA
13.5
Run Test Vehicles with Customer
Initial Startup
19
13.6
Customer Training on Basic Operations/Setup/Packages
Cube® Program. Manual
NA
