B-12 Computer Control
Example of Application Subroutine
EXAMPLE
Goal: Read a microplate at 405 nm, blank on well A1, print the heading
and optical densities for all wells, and send the optical densities for all
wells to the computer.
• Set up a 170-character array (see Table B-4). Each character
should be 1 byte.
• This array represents a file setup similar to a typical file for an
EL312e. The multiple byte strings, such as Array [33 - 34] and
Array [35 - 36] are listed as low byte first and high byte second.
This is how the reader expects the strings to come across.
Array [1]
= Loop through each byte of the
following array starting at 2. Put that
number in Array 1. This is a
checksum for this file structure.
Comments and Order
Array [2-7]
“ “ NOT USED
Array [8-29]
“ “ NOT USED
Array [30]
= 0
Array [31]
= 0
Array [32]
= 0
Array [33-34]
= 0,0
Low byte, high byte
Array [35-36]
= 0,0
Low byte, high byte
Array [37]
= 0
Array [38-45]
= 0s
Array [46-49]
= 0s
Array [50-52]
= “405”
[50] = “4” [51] = “0” [52] = “5”
Filter #1, 405 nm
