PowerWave Operator’s Manual 3-5
Assay Name
At the EDIT NAME screen, it is possible to edit the name assigned to the
assay (Figure 3-4). The assay name can be up to 16 characters.
E
D
I T
N
A
M
E
>
H
B
S
- A
G
1
- /
: S
P
A
C
E
Figure 3-4: Assay Name screen
• Use the ALPHA and NUMERIC keys to change the Assay name.
The cursor is positioned at the first editable field.
• Use the OPTION key to sequentially advance the character
positioned above the cursor. The characters will cycle through the
alphabet (A-Z), with a space following Z.
• Use the LEFT & RIGHT ARROW keys to move the cursor to the
previous or next editable field. The cursor will wrap around the edit
field.
• Use SOFT KEYS 1, 2, 3 & 4 when using alphanumeric characters on
the display above the soft key in the assay name.
