2-12 Installation
Lamp Replacement _______________________________________________
The reader’s lamp should operate without replacement for about 1 billion
flashes. The intensity of the lamp will slowly drop over time until the
reader’s run time self check detects a low signal, and warns the user with a
displayed message.
The bulb should be replaced at this time, using a replacement bulb part
numbered PN 49789. Refer to Figure 2-13 for a detailed view of access to
the lamp assembly.
Figure 2-13: Location of the lamp assembly
Bulb Housing
Bulb Socket
Bottom Plate
Mounting
Hardware
