IQC 5000B Operation Manual
89
Playback Interface
Analog I&Q Outputs
Specification Value
1-dB Bandwidth (MHz) 160 centered at 0 Hz
Power Level (dBm) 0 (fixed)
Amplitude Flatness across 110 MHz
Ban
d
width (dB)
+/-2
VSWR ≤ 1.8:1
Impedance (ohms) 50
Connector SMA Female
2 channels operating simultaneously, baseband, analog
RF Outputs
RF playback capability should be used for testing and system validation only. Do not use RF Playback for normal use.
Channel 1
Specification Value
Center Frequency (MHz) 2400
Information Bandwidth (MHz) 160
Power Level (dBm) 0 to -60 in 1-dB steps
LO Leakage (dBm) -60
VSWR ≤ 1.8:1
Impedance (ohms) 50
Connector SMA Female
