IQC 5000B Operation Manual
91
Trigger Functions
Specification Value
Number of Inputs 2
Voltage levels (VDC) 1 to 3 threshold, 5 maximum
Impedance (ohms) 50
Connector SMA female
Latency from Trigger Valid to First
Sample W
rite (μs)
<1
Re-
Arm Time (ms) <1
Pre-Record Memory (μs) 10
START/STOP RECORDING
Record Types Timed
Manual
Port Configurations Port 1
Port 2
Ports 1 and 2
Ports 1 or 2
Logic (User-Specified) Leading Edge Valid
Trailing Edge Valid (after start p
u
lse or same pulse)
START/STOP PLAYBACK
Playback Modes Timed
Manual
Looped until Trigger
Play between Markers
Port Configurations Port 1
Port 2
Ports 1 and 2
Ports 1 or 2
Logic (User-Specified) Leading Edge Valid
Trailing Edge Valid (after start p
u
lse or same pulse)
