BIRD IQC5000B - Acquisition Bandwidth

Operating Instructions
30
Following is a brief description of the possible record start/stop methods:
 Immediate (Manual) (start and/or stop) – starts/stops a recording immediately on user input.
 Time of day (start and/or stop) – starts/stops a recording at a specified time of day.
 Trigger (start and/or stop) – starts/stops a recording based on trigger parameters.
o 2 TTL-level trigger inputs
o R
ising or Falling edge
 Duration (stop only) – records for a specified duration of time or samples
Acquisition Bandwidth
The Acquisition Bandwidth, Recording Bandwidth, or Recording Span all refer to the instantaneous bandwidth that
will be recorded. With a center frequency at 400 MHz, a 10 MHz acquisition bandwidth would record all signals ± 5
MHz from 400 MHz (395 to 405 MHz).
Keysight and Rohde & Schwarz recor
dings a
re capable of arbitrary acquisition bandwidths below their max
supported span, down to 19.531kHz. Tektronix RSA and Anritsu Field Master Pro recordings are set to discrete
acquisition bandwidths according to set sample rates.
Table 12 - Tektronix RSA6000 Discret
e Acquisition Bandwidths Supported by the IQC5000
I/Q Sampling
Rate (Sp
s)
Data Rate
(Bytes/s)
RSA6000 Acq
BW (Hz)
SR/Acq BW
Divisor
Highest Option
Required
150,000,000 600,000,000 110,000,000 1.3636 110, 05
75,000,000 300,000,000 60,000,000 1.2500 110, 05
50,000,000 200,000,000 40,000,000 1.2500 05
25,000,000 100,000,000 20,000,000 1.2500 05
12,500,000 50,000,000 10,000,000 1.2500 05
6,250,000 25,000,000 5,000,000 1.2500 05
3,125,000 12,500,000 2,500,000 1.2500 05
1,562,500 6,250,000 1,250,000 1.2480 05
781,250 3,125,000 625,000 1.2500 05
390,625 1,562,500 312,500 1.2500 05
195,312.5 781,250 156,250 1.2500 05
97,656.25 390,625 78,125 1.2501 05
48,828.125 195,313 39,062 1.2501 05
24,414.0625 97,656.25 19,531 1.2499 05
