Using IQC5000 with IQC Control
48
For example, if a Max Record File Size of 1TB is selected and then 3TB of data is recorded, the first 1TB of recorded
data will be stored as <Filename>, followed by the next 1TB stored as <Filename2>, and the last 1TB as <Filename3>.
NMEA GPS Port Baud Rate Selection
The baud rate for the NMEA GPS input to the IQC5000 is selectable on the System Tab (Figure 37 on page 46). The
baud rate for the NMEA GPS serial port may be set to 4800, 9600,
or 115200.
System Temperatures
The current temperatures of important internal components may be viewed on the System Tab under System
Temperatures (Figure 37 on page 46). The text color will change from blue to red when a critically
high temperature
has been met.
Sleeping/Waking the IQC5000B-MEM
The IQC5000B-MEM must be set to sleep before disconnecting the external storage hardware or removing an
internal SSD RAID module. This is done by pressing the Sleep button at the top of the window. The Sleep button will
then change to Wake. To use external storage unit or internal SSD RAID module again after being put to sleep, press
the Wake button.
Changing the IQC5000 IP Address
Click the IP Address link next to the IP address to open the Change IP Address menu.
From here, it is possible to change the local reference to the IP a
ddress (in the case that you typed the wrong IP
address when creating a tab), or change the IP address of the IQC5000. Enter the new IP address and select to
either change the local reference or the device IP address, then click Change.
Changing the IQC5000 Subnet Mask
Click the IP Address link next to the IP address to open the Change IP Address menu.
From here, it is possible to change the subnet mask of the IQC500
0.
