Specifications
92
Markers
Specification Value
Number of Inputs 2
Voltage levels (VDC) 1 to 3.3 threshold, 5 maximum
Impedance (ohms) 50
Connector SMA Female
Maximum Allowed per Recording 100,000
Marker Content Date
Time of Day
Latitude
Longitude
Altitude
GS
Sample Number
Latency (μs) <1 from marker valid at connector to insertio
n
in recorded file
Minimum Time between Markers (ms) 1
Reference Clocks
Specification Value
INTERNAL
Frequency (MHz, +/-ppm) 10, +/-10
EXTERNAL (Provided by external input port if active. Otherwise internal clock signal
is used.)
Required Level (dBm) >0 into 50 ohms
Frequency (MHz, +/-ppm) 10, +/-10
Connector SMA Female
Signal Type Square or Sine
Waveform Storage
Specification Value
Internal Solid State NAND Flash
Internal Size (TBytes per unit (ME2)) 2, maximum 2 units
External Rotating Magnetic RAID 0
External Size (TBytes) 8, 15
