IQC 5000B Operation Manual
15
Network Setup
The IQC5000 is a network-controlled device, negotiable on a 10/100/1000 Mbps connection. The unit can be
configured to a custom static IPv4 address and subnet mask.
The IQC5000 is shipped with an IP a
d
dress of 192.168.2.200 and a subnet mask of 255.255.255.0. The IP address
and subnet mask can be changed by using IQC Control and following the instructions outlined in "Changing the
IQC5000 IP Address" on page 48 and "Changing the IQC5000 Subnet Mask" on page 48.
Perform the following steps to set u
p networking
with the IQC5000:
1. For any firewall devices that may limit network port usage, white lis
t the ports/protocols in Table 7.
Table 7 -
Device Type Vendor Device/Software
Device Listening
Port, Protocol
Record/Playback System Bird IQC5000 6644, TCP & UDP
Computer Workstation Bird IQC Control SCPI Co
mmand Server 6634, TCP & UDP
Spectrum Analyzer Keysight
N9010A/B
5025, TCP
N9020A/B
N9030A/B
N9040B
Spectrum Analyzer Rohde and Schwarz FSV/FSW 5025, TCP
Spectrum Analyzer Tektronix
RSA 5000 Series
4000, TCP
RSA 6000 Series
Spectrum Analyzer Anritsu MS2090A 9001, TCP
Auxiliary Software Rohde and Schwarz DigIConf 5026, TCP
Listening Ports and Protocols
2. Complete at least steps 1, 4, 5, 8c, and 8d of the Hardware Setup – Record Section.
3. If desired, change the IQC5000 network settings.
The IQC5000 is shipped with an IP address of 192.168.2.200 and a
subn
et mask of 255.255.255.0. The IP
address and subnet mask can be changed by using IQC Control and following the instructions outlined in
"Changing the IQC5000 IP Address" on page 48 and "Changing the IQC5000 Subnet Mask" on page 48.
4. Configure the Computer Workstation to have a static IP address in the
subnet of 192.168.2.X where the last
octet X is not the same as the IQC5000 IP address (and is also not equal to 1, 254, or 255), with a subnet mask of
255.255.255.0.
5. Configure the Spectrum Analyzer with a static IP address in the
s
ubnet of 192.168.2.X where the last octet X is
not the same as the IQC5000 or Workstation IP addresses (and is also not equal to 1, 254, or 255), with a subnet
mask of 255.255.255.0.
