IQC 5000B Operation Manual
11
7. (Option) Connect the Time/Location Cables:
a. (Option: for time/location-tagging)
Connect a NMEA GPS source to the NMEA GPS input on the
IQC5000. See "NMEA GPS Port Baud Rate Selection" on page 48.
b. (Option: for precision time-tag
ging) Connect an IRIG-B122 source to the IRIG-B input on the IQC5000.
8. Power on the Units:
a. (Option: External Storage Units) Power on External Storage Unit
1 and External Storage Unit 2.
Note: Wait 15 seconds before continuing.
b. (IQC-MEM) Power on the MEM module.
c. Power on in any order:
IQC5000
Spectrum Analyzer
Ethernet Switch
Note: If using PCIe offload, allow IQC t
o boot fully before powering on Computer Workstation.
d. Power on the Computer Workstation.
