Introduction
2
The IQC5000B is capable of I/Q baseband and RF playback. The I/Q Baseband playback is intended for normal use,
RF playback capability should be used for testing and system validation only. Do not use RF Playback for normal use.
Available Equipment
Base Models
The IQC5000B is the second generat
ion of the IQC5000 family of products.
The IQC5000B base model is avail
able in three bandwidths:
Table 2 -
IQC5000B
Model
Description
IQC5040B
Signal recorder with up to 40 MHz record bandwidth.
2 LVDS inputs for each I & Q cha
nnel
, with a maximum data rate of 100 MB/sec per
connector.
Includes IQC5000B-MEM interface module, removable AC power supply
,
IQC Control SW
and documentation on CD.
IQC5160B
Signal recorder with up to 165 MHz record bandwidth.
2 LVDS inputs for each I & Q cha
nnel
, with a maximum data rate of 400 MB/sec per
connector.
Includes IQC5000B-MEM interface module, removable AC power supply
,
IQC Control SW
and documentation on CD.
IQC5255B
Signal recorder with up to 255 MHz record bandwidth.
2 LVDS inputs for each I & Q cha
nnel, with a maximum data rate of 600 MB/sec per
connector.
Includes IQC5000B-MEM interface module, removable AC power supply
,
IQC Control SW
and documentation on CD.
IQC5000B Models
Options and Accessories
The following options and accessories are available for the IQC5000B.
T
able 3 - IQC5000B Options and Accessories
Option
Description
Memory
IQC5000B-MEM Memory interface module for RAID0 storage units.
IQC5000B-ME2
Internal RAID0 SSD disk storage: 2TB. Supports single channel op
e
ration up to 160 MHz
bandwidth. Two units of option ME2 are required for dual channel operation at bandwidths
of 160 MHz or single channel operation at 255 MHz.
IQC5000B-ME0 Additional blank memory module cover for the IQC50
00B-MEM interface module.
IQC5000B-S08
External RAID0 SSD storage: 8TB, supports single and dual channel operation up to 160
MHz bandwidth.
IQC5000B-S15
External RAID0 SSD storage: 15TB, supports single and dual channel operation up to
160 MHz bandwidth.
Recording
IQC5000B-042 Adds second recording channel to support up to 40 MHz recording bandwidth using 2ea
LVDS inputs, I & Q.
IQC5000B-162 Adds second recording channel to support up to 160 MHz recording b
andw
idth using 2ea
LVDS inputs, I & Q.
IQC5000B-XCB LVDS Cable pair (2ea) for Sign
al Anal
yzers supporting up to 255 MHz bandwidth.
IQC5000B-ACB LVDS Cable (1ea) for Keysight X-series Signal Analyzers supporting 40 MHz bandwidth.
