Operating Instructions
28
Controlling the IQC5000
The IQC5000 can be controlled in two possible ways:
 IQC Control Software User Interface: IQC Control Software on the Computer Workstation is the primary
method of control for the IQC5000. See "Using IQC5000 with IQC Control" on page 37.
 Command Server/API: A network sockets server runs in the background while IQC Control is running, and
can be used to programmatically interface with the IQC5000 and connected devices using a SCPI-like lan-
guage. See the IQC5000 API Programming Manual.
Record (Capture, Acquisition)
IQC5000B Storage
The IQC5000B-MEM module supports
reading/writing to external storage as well as reading/writing to internal,
removable drive cartridges.
Table 10 -
IQC5000B IQC-MEM
Internal
SSD Drives
External
SSD Drives
Storage Medium
One or two removable drive cartridges
1 externally connected enclosure, with 16
drives
Memory Depth
Configurations
2000 GB each 8TB or 15TB enclosure
Max Number of Files
10
18
Supported Data Rates
Up to 800 MB/s per cartridge Up to 1600 MB/s
Supported # of Record/
Playback Channels
One with one cartridge installed
OR
one or two with two cartridges installed
One or two
†
†. Two channel recording with external SSD storage enclosures requires using two MiniSAS cables to connect the main
enclosure to the IQC5000B-MEM
File System
ext4
Volume Format
mdadm RAID0
IQC5000B-MEM Supported Storage Options
