Chapter 10 Specifications
FCC Compliance—This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area
is likely to cause harmful interference in which case the user will be required to correct the interference at his own
expense.
Specification Value
Logic Level LVDS
Sample Depth 16-bit I&Q
2 Channels of I&Q Accepts both inputs simultaneously
Connector Four 26-pin MDR
Maximum Data Rate (Mbytes/s) 600 at each connector
Spectrum Analyzer Compatibility Keysight: N9010A/B, N9020A/B, N9030A/B, and N9040B
Rohde & Schwarz: FSV, FSVR, and FSW
Tektronix: RSA 5100/6100
Anritsu: Field Master Pro MS2090A
Minimum Span(kHz) 19.531
Span Resolution (kHz) 19.531
Maximum Acquisition Bandwidth
(MHz)
110 (150 Msamples/s, 16 bits, I&Q)
160 (200 Msamples/s, 12 bits, I&Q)
255 (300 Msamples/s, 14 bits, I&Q)
RF Recording Interface
I & Q Inputs
