BIRD IQC5000B - Page 14

IQC 5000B Operation Manual
3
IQC5000B-GPS GPS/IRIG-B Timing Standard, includes GPS antenna and interface cable.
IQC5000B-RSX
Adapter for Rohde & Schwarz EX-IQ rev 04 interface box. Only compatible with EX-IQ
boxes with serial numbers above 102000.
Playback
IQC5000B-101 Adds single playback channel to support up to 160 MHz; Baseband I & Q (2ea SMA
female) and RF Out at 2.4 GHz, 0dBm (1ea SMA female). Not compatible with options
042, or 162.
IQC5000B-102 Adds second playback channel to
support up to 160 MHz; Baseband I & Q (4ea SMA
female) and one RF Out at 2.4 GHz, 0dBm (1ea SMA female). Requires option 042, or
162.
IQC5000B-CBL
Adds one pair (2ea) of SMA-male to BNC-male cables for IQ analog playback. Each
cable is 5 feet long.
PCIe
IQC5000B-PC3 PCIe x4 Express Card 34 host cable adapter for use in laptop computers and systems that
use option MEM. Includes 2 meter cable.
IQC5000B-PC4 PCIe x8 host adapter for use in
desktop computers and systems that use option MEM; full
height bracket. Includes 2 meter cable.
IQC5000B-PC7
PCIe x8 to x4 cable, 2 meter length.
Computer Workstation
IQC5000B-WS1 Rackmounted SigAnalyst Workstation
Dual Xeon, Quad-Core Workstation, 64GB RAM with 128 TB HDD Stora
ge Archive (96 TB
usable)
IQC5000B-WS2 Rackmounted SigAnalyst Workstation
Dual Xeon, Quad-Core Workstation, 64GB RAM with 128 TB HDD Stora
ge Archive (96 TB
usable), Spectro-X and RF Editor software packages
WC-RF-EDITOR RF Editor Signal Generation software
SPECTRO-X
Spectro-X Advanced Signal Analysis software
Accessories
IQC5000B-RM2 19 inch Rack Mount Kit for IQC5000B with Option MEM (3U)
IQC5000B-1A5 Transit Case for IQC5000B. Case can hold the IQC5000B, IQC5000B-MEM and related
accessories.
IQC5000B-ENL Rack enclosure to house IQC5000B,
down converter, 2ea solid state data packs,
upconverter, workstation, storage archive and power distribution
IQC5000B-BKT
Non-rackmount bracket for affixing the IQC5000B to the IQC5000B-MEM interface
module
Warranty
IQC5000B-EX1 Extends factory warranty of IQC5000B by one additional year
IQC5000B-EX2 Extends factory warranty of IQC5000B by two additional years
IQC5000B-EX3 Extends factory warranty of IQC50
00B by three additional years
IQC5000B-EX4 Extends factory warranty of IQC50
00B by four additional years
Option Description
