Table 13 - Tektronix RSA5000B Discrete Acquisition Bandwidths Supported by the IQC5000
I/Q Sampling
Rate (Sp
s)
Data Rate
(Bytes/s)
RSA5000B Acq
BW (Hz)
SR/Acq BW
Divisor
Highest Option
Required
200,000,000 800,000,000 165,000,000 1.2121 B16X or B16XHD
200,000,000 800,000,000 85,000,000 2.3529 B85 or B85HD Only
100,000,000 400,000,000 80,000,000 1.2500 B85 or B85HD
50,000,000 200,000,000 40,000,000 1.2500 B40
25,000,000 100,000,000 20,000,000 1.2500 B25
12,500,000 50,000,000 10,000,000 1.2500 B25
6,250,000 25,000,000 5,000,000 1.2500 B25
3,125,000 12,500,000 2,500,000 1.2500 B25
1,562,500 6,250,000 1,250,000 1.2500 B25
781,250 3,125,000 625,000 1.2500 B25
390,625 1,562,500 312,500 1.2500 B25
195,312.5 781,250 156,250 1.2500 B25
97,656.25 390,625 78,125 1.2500 B25
48,828.125 195,313 39,062 1.2500 B25
24,414.0625 97,656.25 19,531 1.2500 B25
Table 14 - Tektronix RSA5000A Discrete Acquisition Bandwidths Supported by the IQC5000
I/Q Sampling
Rate (Sp
s)
Data Rate
(Bytes/s)
RSA5000A Acq BW
(Hz)
SR/Acq BW
Divisor
Highest Option
Required
150,000,000 600,000,000
165,000,000 (Opt. 110)
85,000,000 (Opt. 85)
1.3636 (Opt. 110)
1.7647 (Opt. 85)
110 (Opt. 110) or
85 (Opt. 85)
75,000,000 300,000,000 60,000,000 1.2500 110 or 85
37,500,000 150,000,000 30,000,000 1.2500 110 or 85
50,000,000 200,000,000 25,000,000 2.0000 25
25,000,000 100,000,000 20,000,000 1.2500 25
12,500,000 50,000,000 10,000,000 1.2500 25
6,250,000 25,000,000 5,000,000 1.2500 25
3,125,000 12,500,000 2,500,000 1.2500 25
1,562,500 6,250,000
1,250,000 1.2500 25
781,250 3,125,000 625,000 1.2500 25
390,625 1,562,500 312,500 1.2500 25
195,312.5 781,250 156,250 1.2500 25
97,656.25 390,625 78,125 1.2500 25
48,828.125 195,313 39,062 1.2500 25
24,414.0625 97,656.25 19,531 1.2500 25
