Table 17 - IQC5000 Supported Playback Acquisition Bandwidth- Rohde & Schwarz
I/Q Sampling Rate
(Sp
s)
Data Rate
(Bytes/s)
Rohde & Schwarz
Reco
rding Spans (Hz)
FSV/
FSVR
FSW
300,000,000 down to
31,250,000 in any step
supported by the signal
analyzer
4x IQ
Sampli
n
g
Rate
40,000,000
down to
25,000
,000
160,000,000
down to
25,000,000
25,000,000 100,000,000 20,000,000 20,000,000
12,500,000 50,000,000 10,000,000 10,000,000
6,250,000 25,000,000 5,000,000 5,000,000
3,125,000 12,500,000 2,500,000 2,500,000
1,562,500 6,250,000 1,250,000 1,250,000
781,250 3,125,000 625,000 625,000
Table 18 - IQC5000 Supported Playback Acquisition Bandwidth- Tektronix
I/Q Sampling Rate
(Sp
s)
Data Rate
(Bytes/s)
Tektronix
Recording Spans (Hz)
RSA6000 RSA5000A RSA5000B
300,000,000 down to
31,250,000 in any step
supported by the signal
analyzer
4x IQ
Sampli
n
g
Rate
110,000,000
down to
25,000
,000
110,000,000
dow
n to
25,000,000
165,000,000
dow
n to
25,000,000
25,000,000 100,000,000 20,000,000 20,000,000 20,000,000
12,500,000 50,000,000 10,000,000 10,000,000 10,000,000
6,250,000 25,000,000 5,000,000 5,000,000 5,000,000
3,125,000 12,500,000 2,500,000 2,000,000 2,500,000
1,562,500 6,250,000 1,250,000 1,000,000 1,250,000
781,250 3,125,000 625,000 500,000 625,000
