Compact monitor Setting of sensor sensitivity and input range
Part D
- 24 - C100585.002 Communication Vers. 03 © VC-6000
TM
Compact monitor Dec 09
9 Setting of sensor sensitivity and input range
9.1 General
The sensor sensitivity and input range are dependent on the measurement
task.
You should note that the settings for the sensitivity must correspond to the
sensitivity of the connected sensors. The correct data is as a rule marked in
the technical documentation for the sensor.
9.2 Setting up the sensor sensitivity
Setting up is shown in the following example:
The sensitivity of a sensor that will be connected is to be set to the value of
50 mV/g. The signal-flow chart shows the acceleration sensor is connected
to the sensor module Sensor03.
Block level
USER MENU
NEXT
DATE & TIME
NEXT
SYSTEM
NEXT
LOGBOOK
NEXT
SENSOR 01
NEXT (until SENSOR03 block appears)
SENSOR 03
ENTER BUTTON
SENSOR 03
Socket no.
NEXT
SENSOR 03
Sensitivity
ENTER BUTTON
Sensitivity
+00100.00mV/g
With NEXT select the digit position to
be changed.
Sensitivity
+001
00.00mV/g
Changing the digit:
Push and hold SHIFT, then push
NEXT / PREVIOUS to change the digit.
Sensitivity
+000
00.00mV/g
