VC-6000
TM
Compact monitor Part D Setting of limit setpoints and time delays
- 28 - C100585.002 Communication Vers. 03 © VC-6000
TM
Compact monitor Dec 09
10 Setting of limit setpoints and time delays
10.1 General
When limit setpoints (MONITOR blocks) are entered into the signal-flow
charts, there is the option to adapt the limit setpoints and time delay.
Caution !
The user bears the responsibility for any consequences
that arise due to incorrect operation or incorrect parameter
settings!
Special care is necessary when setting up alarm setpoints (Monitor blocks).
When changing these settings the user should always make changes to the
entered data (limit type, limit setpoints, time delays, etc.) that are consistent
and correct for the machine being monitored. Illogical entries (e.g.
monitoring a very high value for violations that are below the limit) will not be
intercepted by the system and may, because of improper operation, e.g.
result in a machine shutdown.
10.2 Setting up the limit type
Changing the limit type from <High> to <Low> e.g. in MONITOR (ABS)
block:
Block level
USER MENU
NEXT
DATE & TIME
NEXT
SYSTEM
NEXT
LOGBOOK
NEXT
SENSOR 01
NEXT (until the Monitor block appears)
MONITOR(ABS)01
ENTER BUTTON
MONITOR(ABS)01
Alarm Type
NEXT
MONITOR(ABS)01
Limit type
NEXT
Limit type
High
NEXT
Limit type
Low
ENTER BUTTON
Limit type
Low
