VC-6000
TM
Compact monitor Part D Logbook
- 36 - C100585.002 Communication Vers. 03 © VC-6000
TM
Compact monitor Dec 09
11 Logbook
11.1 General
Various types of events are recorded in the Logbook. They are divided into
three groups.
1. System: Messages about events that occur in the system, e.g.
an error in the monitoring system
2. Access: Login and Logoff events by a SUPER USER. This
concerns also all entries through the User Terminal.
3. Monitoring: Limit violations and alarm signals
The Logbook is in a block in the dialogue of the
VIBROCONTROL 6000 Compact monitor and can be viewed using the
User-terminal.
11.2 How are Logbook entries displayed?
The Logbook is reached by pushing the NEXT button each time the
dialogue jumps to the next block, until the Logbook is reached. With
ENTER you reach the first sub-menu <Show entries >. Pushing ENTER
again leads to an entry. If you push ENTER again the most recent entry
will be displayed. NEXT leads to older entries in time, PREV to newer
entries in time. If there is no longer a change when a button is pushed it
simply means there are no further entries. Please note that two sequential
and identical entries will also produce the same appearance. With ESC
you will return to the sub-menu <Show entries>.
In the sub-menu <Filtered entries> one of the three entry groups can be
selected. When you select a group, and then select the sub-menu <Show
entries> only the entries of the selected group will be displayed. At initial
delivery the entry filter is set to <all entries>.
Note:
The logbook may also contain messages when the instrument is first
delivered. This can happen due to the pre-delivery testing procedure or
during the configuration with customer-specific parameter settings.
