11.6.3 Logbook entries for System events
Logbook entry Cause Responsible Block
Logbuff. Full The logbook buffer is full, some
messages are lost.
LOGBOOK
Pwrfailure i1 Primary voltage failure in
internal power supply
Pwrfailure i2 Secondary voltage failure in
internal power supply
Pwrfailure e1 Primary voltage failure in
external power supply
Pwrfailure e2 Secondary voltage failure in
external power supply
Power up i1 Inernal primary voltage on
Power up i2 Internal secondary voltage on
Power up e1 External primary voltage on
Power up e2 External secondary voltage on
Wrong Module The given socket is equipped
with an incorrect module
SENSOR ##,
SENSOR (A/B)##,
RELAY ##,
DC_OUT ##
Over-range The sensor signal lies outside
the specification
SENSOR ##
Sensor NOK The sensor in the given socket
is producing an OK-fault
SENSOR ##,
SENSOR (A/B)##
Over-range A Signal channel A of SENSOR
(A/B) lies outside the
specification.
SENSOR (A/B)##
Over-range B Signal channel B of SENSOR
(A/B) lies outside the
specification.
SENSOR (A/B)##
Meas.canceled Trigger signal too fast CYCLE-DC ##
Note:
The logbook entries “Overrange” and sensor NOK” appear only once per
channel in the logbook, even if the event arises several times. New entries
take place, if [logout with store] took place (initialization of the logbook).
