Compact monitor Juni 2014 C100575.002 Introduction Vers.10 - 18 -
Switch conditions and their meaning
♦ The green LED shows the current status of a relay output.
• Relay enable off:
The relay does not operate, a limit violation is displayed only by the
LEDs
• Relay enable on:
The relay operates with a limit violation
♦ The red LED signals an existing announcement status, which as a rule
is linked to an existing Alert or Danger alarm.
♦ The yellow LED is used for signalling supplementary information, e.g.
<Trip override> active, or <Relay latching> active.
Note:
The status of the logical connection between the conditions of
TRIPOVERRIDE and ACKNOWLEDGE can be queried as a parameter in
the Logic block using the User Terminal.
