Compact monitor Juni 2014 C100575.002 Introduction Vers.10 - 19 -
LEDs – Status and meanings:
Case LED
green
LED
yellow
LED
red
Meaning
enabled disabled
1
green
green
off
off
There are no violations.
2
green
green
off
red
A limit violation exists that has not been
reset.
3
green
green
off
red
A limit violation exists that has been
reset.
4
green
green
off
red
A limit violation existed but is no longer
present. The limit violation has not been
reset.
5
green
green
yellow
off
Only with latching relay output: A limit
violation existed that has been reset.
The relay is still latched and has not
been reset.
6
green
green
yellow
off
<Trip override> active
7
green
green
off
red
A limit violation has occurred but no
longer exists. The violation has not
been acknowledged.
The relay was latched but has been
reset.
8
green
yellow
red
Relay has an error function
9
off
off
off
Relay not configured
10
Wrong TIM module or TIM module
corrupted
Legend:
Green
LED
Meaning Status of the
LEDs
Meaning
LED is off
Relay is enabled
LED is on
Relay is disabled
LED flashing at 0,5
Hz
Relay in service
LED flashing at 2
Hz
LED flashing at 8
Hz
