1.4.3 System: Connections X20 to X27
The connections X20 to X27 are system connections, and their function and
connection layout is dependent on the hardware equipment.
1.4.3.1 Internal power supply: X20 – Power supply
The internal power supply of the Base Module is provided with power
through the connection X20.
According to the delivered Base Module a distinction must be made between
AC power and DCpower.
Connection
X20
Power supply 230 V AC permissible power range:
90 ... 264 V AC / 50 ... 60 Hz
Pin 1 L IN Live
Pin 2 N IN Neutral
Pin 3 PE IN Ground (Protective Earth)
Connection
X20
Power supply 24 V DC (48 V DC)
permissible power range 20 ... 75 V DC
Pin 1 20-75 V DC IN Plus (+)
Pin 2 free
Pin 3 0v IN Minus (-)
Caution!
Maximally 75 V smoothed DC voltage may be attached!
