VC-6000
TM
Compact monitor Part B 1-channel input module for displacement sensors
- 28 - C100584.002 Module Vers. 08 © VC-6000
TM
Compact monitor Nov. 2014
4.3 Technical data
4.3.1 Electrical properties
Input:
Input voltage range -21,5 V ... + 2,5 V
Frequency range of input signal > 0 ... 50 kHz
Input impedance 200 kΩ
Sensor Sensitivity analogue adjustable
Amplification in 8 steps from 1 ... 80
(6 0,75 %)
Buffered output:
Output voltage range min. -21 V ...+ 2 V
Frequency range of output signal > 0 ... 50 kHz
Output load min. 10 kΩ
Amplification 1 (6 2 %)
Phase shift 20 kHz < 15°
50 kHz < 35°
Short-circuit proof Yes
Sensor power supply:
Power supply - 24 V DC
Current consumption max. 30 mA
4.3.2 Equipment and signalling
♦ Possible socket positions on the Base Module X1_M X2_M X3_M
♦ Corresponding connections on the Base Module X1 X2 X3
♦ Connection layout with a D-TIM
S-SIM Pin layout connection X1/X2/X3
PIN Signal Explanation
1 0 V Sensor power supply
2 -24 V Sensor power supply
3 COM Sensor signal reference potential
4 SIG Sensor signal
5 Not connected
6 0 V 0 V
