2-channel Relay output module Part B VC-6000
TM
Compact monitor
© VC-6000
TM
Compact monitor Nov, 2014 C100584.002 Module Vers. 08 - 39 -
8.2.2 Connection plug layout
Relay output module pin layout connections X1/X2/X3
PIN Signal Explanation
1
ARM RelA
Arm, relay A
2
NO RelA
Normally-open contact, relay A
3
NC RelA
Normally-closed contact, relay A
4
ARM RelB
Arm, relay B
5
NO RelB
Normally-open contact, relay B
6
NC RelB
Normally-closed contact, relay B
