Upgrading The Computer
Removing the Rear Component Cover 6 - 7
6
4. Slide the rear cover up in the direction of the arrow , until the bottom marker of
the rear cover icon is aligned with the marker on the side of the computer .
5. Carefully remove the rear cover , and set it aside.
Figure 6 - 5
Rear Cover Unlock
Figure 6 - 6
Rear Cover Remove
3
4
4
4
4
3
4
5
5
