Blue Sonic Multimedia PC - System Map: Front View - Model B

System Map: Front View - Model B 1 - 7
Quick Start Guide
1
System Map: Front View - Model B
Figure 1 - 3 - Front View - Model B
1. Optional Built-In PC Camera
2. PC Camera LED
3. Built-In Microphone
4. LCD with Multi Touch Screen
5. Power Button
6. Function Buttons
7. Power & System Activity LED
Indicators
8. Speakers
1
2
5
4
6
3
7
88
5
67

Multi Touch Screen
Note that Model B computers incorporate a
touch screen, Model A computers do not.
