Blue Sonic Multimedia PC - Page 135

Upgrading The Computer
Upgrading the Hard Disk Drive/SSD 6 - 11
6
6. Remove screws - from the hard disk bracket
7. Remove the left and right side brackets from the HDD.

Screwdriver Types
Make sure you use a
small manual screw-
driver, and not an elec-
trical screwdriver, in
the course of the up-
grade/disassembly pro-
cedures outlined here,
due to the delicate na-
ture of the screws.
Figure 6 - 9
3.5" HDD Assembly
Removal
8
13
8
9
11
10
13
12
