Bluetooth & WLAN Combo Module (Windows 7) D - 57
Windows 7
Windows 7
3rd Party Bluetooth (V4.0) Combo Driver Installation
Note this driver is required for the 3rd Party combo Bluetooth and WLAN module
(Bluetooth V4.0) only.
1. Before installing the driver make sure the Bluetooth module is powered
on (
use the
On Screen Display
button to
toggle power to the module
), then
insert the Device Drivers & Utilities + User’s Manual disc into the CD/
DVD drive. If a Found New Hardware window appears, click/tap Cancel
in all windows that appear, and then proceed to install the driver as below.
2. Click/tap Option Drivers (button).
3. Click/tap 4.Install Combo BT Driver > Yes.
4. Click/tap Next (if a prompt appears to ask you to turn the Bluetooth power
on, use
the
On Screen Display
button to do so, otherwise the driver will not
be installed).
5. Click/tap Finish to restart the computer.
6. See “Standard Bluetooth Configuration in Windows 7” on page D - 59 for
configuration instructions.
