Figure 4.60 Detaching the screw terminal block
4.9.2 ANI 0016 A Annunciator Module
Figure 4.61 ANI 0016 A Annunciator Module
The annunciator module has 16 red and 16 yellow LEDs for displaying the operating states of
16 definable detection points.
The activation of each LED is defined using the FSP-5000-RPS programming software.
This defines which detection points will activate the LEDs in which state.
The technical data can be found in Section 7.5.1 ANI 0016 A Annunciator Module, page 159.
