152 en | Technical Data Modular Fire Panel
F.01U.028.089 | 8.0 | 2011.07 System Description Bosch Sicherheitssysteme GmbH
7 Technical Data
7.1 System Limits
Panels/remote keypads in the network Max. number
Loop topology 32
Bus topology 8
Addresses Max. number
Standalone 4096
In network, total 32512
In network, per panel 2032
Detection points/detector zones Max. number
Standalone 4096
In network, total 32512
In network, per panel 2032
Notification appliance circuit groups per loop 7
Per fire panel Max. number
Sets, e.g. bypass group 192
Functional modules 46
Printer 4
Alarm counters (external, internal, testing) 3
Entries in the event database 10000
FSP-5000-RPS configuration interfaces (USB, COM) 2
Timer channels 20
Time control programs 19
Configuration for a Specific Day 365
Permission levels 4
User profiles 200
Sum counters and counters (in total) 60,000
Exportable objects including counters in the entire panel cluster
(without pre-defined system counters)
2000
Importable objects including counters (without pre-defined system
counters)
2000
Automatic connections to FMR-5000 3
Block of State-Dependent Rules (depending on what kind of
activations are possible for the object in question)
8
Number of rules within a block (depending on the number of rules
from other blocks that are connected to the same object)
254
Number of functional modules Max. number
ANI 0016 A 32
BCM-0000-B 8
CZM 0004 A 32
