Modular Fire Panel Product Description | en 23
Bosch Sicherheitssysteme GmbH System Description F.01U.028.089 | 8.0 | 2011.07
2.7 Networking
Depending on the intended application, different panel controllers and remote keypads can
be divided into groups and defined as network nodes or local nodes. As a rule, within any
given group, only the status of control panels within the defined group can be displayed. The
status of all control panels can be displayed and/or processed from network nodes,
irrespective of the group to which the panels belong.
The following connection topologies can be used for networking via the CAN1 and CAN2
interfaces:
–Non-redundant bus via CAN1
– Redundantly via the CAN1 and CAN2 buses
– Redundantly via CAN1 and CAN2 as a loop
The rules that must be applied for network configuration can be found in
Section 3.2 Networking.
FOC Networking
In a loop, two panels can be connected using fiber optic cables via CAN/FOC adapters. The
CAN/FOC adapters from Phoenix Contact and EKX are available for this purpose (see
Section FOC Networking, page 27).
Product group Product name Connection via
Fire service devices
FBF 100 LSN LSN classic
FAT 2002 RE
IOS 0020 A + IOP 0008 A (+ ADP-NB adapter
2
)
FAT 2002 – IOS 0020 A + FLM-420-I2
– IOS 0020 A + FLM-420-I8R1
– IOS 0020 A + FLM-420-O1I1
– IOS 0020 A + FLM-420-O8I2
FMA-AT 2000-IP
FMA-AT 2000-ISDN
FMA-AT 2000-GSM
ENO 0000 B
BGÜ 20 BGÜ 40
BGÜ 40/30
ENO 0000 B
2) Included in the scope of delivery of the FAT 2002 RE
Key deposits Connection via: ENO 0000 B
Door controls Connection via: – FAA-MSR 420
– FLM-420-RHV
