Bosch FPA-5000 System Description

Modular Fire Panel Technical Data | en 153
Bosch Sicherheitssysteme GmbH System Description F.01U.028.089 | 8.0 | 2011.07
7.2 Power loss of FPA-5000 Components
ENO 0000 B 8
FPE-5000-UGM 4
IOP 0008 A 32
IOS 0020 A 4
IOS 0232 A 4
LSN 0300 A 32
LSN 1500 A 11
NZM 0002 A 8
RMH 0002 A 32
RML 0008 A 32
Number of functional modules Max. number
Component Power loss
ANI 0016 A 0.62 W (all LEDs lit)
BCM-0000-B – 0.96 W (controller + green LED lit)
– 1.44 W (per AUX with 1.06 A load)
CZM 0004 A – 1.65 W (for a line with 100 mA load)
– 3.36 W (for 4 lines with 100 mA load each)
ENO 0000 B – 1.44 W (1 relay activated)
– 7.80 W (4 relays activated + key deposit heating
active)
FMR-5000 5.40 W
FPE-5000-UGM 0.17 W
IOP 0008 A 0.24 W
IOS 0020 A 0.36 W
IOS 0232 A 0.36 W
LSN 0300 A – 1.50 W (AUX with 490 mA load)
– 2.72 W (LSN)
LSN 1500 A – 8.00 W (AUX)
– 14.70 W (LSN with 750 mA load)
MPC-xxxx-B 4.92 W
NZM 0002 A 0.96 W
PRD 0004 A 0.33 W
PRS 0002 A 0.18 W
RMH 0002 A 1.16 W
RML 0008 A 1.04 W (all relays activated)
UPS 2416 A 28.00 W

Bosch FPA-5000 Specifications

General

Max Number of Detectors per Loop	254
Display	LCD
Network Capability	Yes
Power Supply	24 V DC
Operating Temperature	-5°C to +50°C
Communication Ports	Ethernet
Humidity Range	95% non-condensing
