Bosch FPA-5000 System Description

Modular Fire Panel Installation | en 51
Bosch Sicherheitssysteme GmbH System Description F.01U.028.089 | 8.0 | 2011.07
4.2 Quick Installation Guide
1. Keep to hand:
– The installation instructions supplied with the relevant components (housing, frame,
cables etc.) (see Section 4.3 Installation of Housing Components).
– The required tools.
An overview of the required tools can be found in the installation instructions.
2. Preparation
– Lay the pre-cabling.
– Optional: network cabling.
3a. Installation of wall mounting housing
Install:
–Housing
– Optional: accessories for housing
– Power supply bracket
– Power supply unit and batteries
–Panel rail
– Panel controller
– Functional modules
3b. Installation of frame installation housing
Install:
–Mounting frames
–Housing
– Optional: accessories for housing
– Power supply unit and batteries
–Panel rail
– Panel controller
– Functional modules
4. After installation
Store all documents.

Bosch FPA-5000 Specifications

General

Max Number of Detectors per Loop	254
Display	LCD
Network Capability	Yes
Power Supply	24 V DC
Operating Temperature	-5°C to +50°C
Communication Ports	Ethernet
Humidity Range	95% non-condensing
