130 en | Installation Modular Fire Panel
F.01U.028.089 | 8.0 | 2011.07 System Description Bosch Sicherheitssysteme GmbH
4.13 THP 2020 A Thermal Printer
Figure 4.85 THP 2020 A Thermal Printer
Scope of Delivery
– Sheet steel housing, painted
– Thermal printer (installed), with connection cable
– Plastic front panel
– Accessories pack with installation materials
Required for Installation
– FSH 0000 A Mounting Frame Small, or
– FRS 0019 A Rack Installation Kit, Small
Figure 4.86 THP 2020 A mounting frame/installation kit
General Information
– The following information can be sent to the printer:
– Operating procedures on the panel (e.g. daytime operation)
– Alarm and fault messages
– Plain text; programming is carried out via the programming software FSP-5000-RPS.
– On every printout:
– The current date and the time are specified.
– The most recent event is always at the top
– Entries stored in the history log can also be printed if the operator has the appropriate
operational authorization.
– Always ensure the printer cover panel is closed properly. If the device contact is opened,
incoming messages cannot be printed, even at a later date, as the printer does not have
its own message memory. In this case, the message only appears on the display of the
control panel.
– If the supply of paper is nearing its end, this is indicated by a message on the display of
the control panel. When this message appears, you still have enough paper on the roll to
print approx. 200 lines of text.
FSH 0000 A
THP 2020 A
FRS 0019 A
THP 2020 A
