Bosch FPA-5000 System Description

66 en | Installation Modular Fire Panel
F.01U.028.089 | 8.0 | 2011.07 System Description Bosch Sicherheitssysteme GmbH
4.3.5 Installation Kits for 482.6 mm (19”) Racks
FRK 0019 A Rack Installation Kit for All Wall Mounting Housings
The FRK 0019 A Rack Installation Kit is used to install wall mounting housings in 482.6 mm
(19") racks.
The two mounting brackets in the universal installation kit are fitted at distance H (see
Figure 4.14). The dimensions of H for the different wall mounting housings can be found in the
table below:
Figure 4.14 FRK 0019 A housing installation
Housing H
PSS 0002 A 217 mm
DIB 0000 A 217 mm
PSB 0004 A 308 mm
HCP 0006 A 409 mm
HBC 0010 A 609 mm
HBE 0012 A 609 mm
H

Bosch FPA-5000 Specifications

General

Max Number of Detectors per Loop	254
Display	LCD
Network Capability	Yes
Power Supply	24 V DC
Operating Temperature	-5°C to +50°C
Communication Ports	Ethernet
Humidity Range	95% non-condensing
