Installation of the power supply unit is described in Section 4.9.13 RMH 0002 A Relay Module
for Mains Voltage, page 123.
7.6.2 FPP-5000-TI Trouble Interface
The module is described in Section 4.12 FPP-5000 External Power Supply Unit Kit 24 V/6 A,
page 128.
7.6.3 FPP-5000-TI13 Communication Interface
The module is described in Section 4.12 FPP-5000 External Power Supply Unit Kit 24 V/6 A,
page 128.
Max. output 160 W (permanent)
Maximum load of fault outputs BAT FAULT,
AC FAULT, and collective fault
0 V/0 - 20 mA
2 voltage outputs, switchable +24 V/2.8 A (20.4 - 30 V), battery buffered
Housing material Sheet steel, painted
Housing color Slate gray, RAL 7015
Front: anthracite gray, RAL 7016
Dimensions, installed (H x W x D) approx. 527 x 456 x 326 mm
Protection class as per EN 60950 Class I equipment
Permissible operating temperature -5 °C to 50 °C
Permissible storage temperature -20 °C to 60 °C
Relative humidity Max. 95 % non-condensing
Cooling Ventilation without ventilator
Input voltage 15 V DC to 30 V DC
Maximum current consumption 1.15 mA (at 24 V), from LSN
Protection category (IEC 60529) IP 20
Addressing using eight DIP switches
Space required (H x W x D) approx. 127 x 96 x 60 mm
Input voltage 15 V DC to 33 V DC
Current consumption
– From panel rail at 24 V DC
–From LSN
–13.2mA
–3.25mA
Protection category (IEC 60529) IP 20
Space required (H x W x D) approx. 127 x 96 x 60 mm

Bosch FPA-5000 Specifications

General

Max Number of Detectors per Loop	254
Display	LCD
Network Capability	Yes
Power Supply	24 V DC
Operating Temperature	-5°C to +50°C
Communication Ports	Ethernet
Humidity Range	95% non-condensing
