Modular Fire Panel Installation | en 87
Bosch Sicherheitssysteme GmbH System Description F.01U.028.089 | 8.0 | 2011.07
4.7.2 PRD 0004 A Panel Rail Long for 4 Modules
The PRD 0004 A Panel Rail Long has four module slots and is supplied with 24 V DC by the
BCM. An integrated voltage converter then generates the 5 V DC operating voltage required by
the modules.
Figure 4.37 PRD 0004 A connections
The technical data can be found in Section 7.3.4 PRD 0004 A Panel Rail Long for 4 Modules,
page 156.
HNAC
LNAC
V
4
2+
D
N
G
+
DIM
HNAC
LNAC
V42+
DN
G
DIM
CANH
CANL
+24V
GND
+5V
MID
X
R
E
120
Ω
+
