Bosch FPA-5000 System Description

154 en | Technical Data Modular Fire Panel
F.01U.028.089 | 8.0 | 2011.07 System Description Bosch Sicherheitssysteme GmbH
7.3 Housing and Accessories
7.3.1 Housings for Frame Installation
7.3.2 Housings for Wall Mounting
7.3.3 PRS 0002 A Panel Rail Short for 2 Modules
Housing material Sheet steel, painted
Housing color Slate gray, RAL 7015; front: anthracite gray, RAL 7016
Housing type Dimensions (H x W x D) Dimensions including
mounting frame
Weight
CPH 0006 A approx. 638 x 440 x
145 mm
approx. 663 x 455.5 x
236 mm
12.5 kg
MPH 0010 A approx. 638 x 440 x
145 mm
approx. 663 x 455.5 x
236 mm
12.5 kg
EPH 0012 A approx. 638 x 440 x
145 mm
approx. 663 x 455.5 x
236 mm
13.2 kg
PMF 0004 A approx. 502 x 440 x
145 mm
approx. 527 x 455.5 x
236 mm
11.4 kg
PSF 0002 A approx. 267 x 440 x
145 mm
approx. 292 x 455.5 x
236 mm
6.4 kg
USF 0000 A approx. 267 x 440 x
145 mm
approx. 292 x 455.5 x
236 mm
6.4 kg
Housing material Sheet steel, painted
Housing color Slate gray, RAL 7015; front: anthracite gray, RAL 7016
Housing type Dimensions (H x W x D) Weight
HCP 0006 A approx. 638 x 440 x 149 mm 12.5 kg
HBC 0010 A approx. 840 x 440 x 149 mm 17.0 kg
HBE 0012 A approx. 840 x 440 x 149 mm 17.0 kg
PSB 0004 A approx. 502 x 440 x 149 mm 11.4 kg
PSS 0002 A approx. 267 x 440 x 149 mm 6.4 kg
DIB 0000 A approx. 267 x 440 x 149 mm 6.4 kg
Input voltage +5 V DC via MPC/+24 V DC via BCM
Current consumption at
24 V DC
7.6 mA
Output voltage +5 V DC operating voltage for modules
+24 V DC for following PRD 0004 A Panel Rails
Permissible operating
temperature
-5 °C to 50 °C
Permissible storage
temperature
-20 °C to 60 °C
Material and color ABS plastic (UL94 V-0), satin finish, anthracite, RAL 7016

Bosch FPA-5000 Specifications

General

Max Number of Detectors per Loop	254
Display	LCD
Network Capability	Yes
Power Supply	24 V DC
Operating Temperature	-5°C to +50°C
Communication Ports	Ethernet
Humidity Range	95% non-condensing
