Bosch FPA-5000 System Description

Modular Fire Panel Table of Contents | en 3
Bosch Sicherheitssysteme GmbH System Description F.01U.028.089 | 8.0 | 2011.07
Table of Contents
1 Safety Instructions 6
2 Product Description 7
2.1 FPA-5000 with Functional Modules 7
2.2 MPC Panel Controller 11
2.3 FMR-5000 Remote Keypad 13
2.4 Housings for Frame Installation 14
2.5 Housings for Wall Mounting 18
2.6 System Overview of FPA-5000 with Peripherals 20
2.7 Networking 23
2.8 Connection to BIS 24
2.9 Connecting a Plena Voice Alarm System 24
3 Planning 25
3.1 General Information 25
3.2 Networking 27
3.3 Structures in Local Security Network 31
3.4 Detection Points 32
3.5 Addressing 33
3.6 Achievable Cable Length with LSN 0300 A 34
3.7 Achievable Cable Length with LSN 1500 A 37
3.8 Examples of Housing Equipment 40
3.9 Configuration of BCM Battery Controller Module 42
3.10 Redundancy 47
4 Installation 49
4.1 General Information 49
4.2 Quick Installation Guide 51
4.3 Installation of Housing Components 52
4.3.1 Installation Instructions for Housing 53
4.3.2 Installation Dimensions for Wall Mounting Housing 55
4.3.3 Installation Dimensions for Frame Installation Housing 61
4.3.4 Installation Dimensions for Mounting Frames 64
4.3.5 Installation Kits for 482.6 mm (19”) Racks 66
4.4 Accessories for Housing 69
4.4.1 RLE 0000 A Junction Board 69
4.4.2 HMP 0003 A Mounting Plate for Mounting Frame 70
4.4.3 FPO-5000-EB Earth Bar 71
4.5 Power Supply Brackets 72
4.5.1 FPO-5000-PSB-CH Power Supply Bracket 74
4.5.2 FPO-5000-PSB1 Power Supply Bracket 77
4.6 UPS 2416 A Universal Power Supply 24 V/6 A 79
4.7 Panel Rails 84
4.7.1 PRS 0002 A Panel Rail Short for 2 Modules 84
4.7.2 PRD 0004 A Panel Rail Long for 4 Modules 87
4.8 MPC Panel Controller 90

Bosch FPA-5000 Specifications

General

Max Number of Detectors per Loop	254
Display	LCD
Network Capability	Yes
Power Supply	24 V DC
Operating Temperature	-5°C to +50°C
Communication Ports	Ethernet
Humidity Range	95% non-condensing
