158 en | Technical Data Modular Fire Panel
F.01U.028.089 | 8.0 | 2011.07 System Description Bosch Sicherheitssysteme GmbH
7.4 Panel Controller and Remote Keypad
7.4.1 MPC
Installation of the device is described in Section 4.8 MPC Panel Controller, page 90.
7.4.2 FMR-5000 Remote Keypad
LCD display/touch screen LCD display with 320 x 240 pixels, touch screen with
127.5 mm x 170 mm active area
Operating and display elements 22 buttons, 1 key switch, 11 LEDs, 1 reboot button
Interfaces CAN1, CAN2, Ethernet 100BaseTX, USB
(max. 3 m cable length), RS232 (max. 3 m cable length)
Signal inputs IN1/IN2
Max. length of CAN cable for
system networking
L
max
= 1000 m, depending on configuration, cable type
and topology
Input voltage 20 V DC to 30 V DC
PRS 0002 A power supply +5 V DC ± 4.5 %/max. 500 mA
Maximum current consumption – Standby mode: 120 mA at 24 V DC
– In case of alarm: 205 mA at 24 V DC
Permissible operating temp. -5 °C to 50 °C
Permissible storage temperature -20 °C to 70 °C
Space required (H x W x D) 190 x 404 x 60 mm
Weight Approx. 2 kg
LCD display/touch screen LCD display with 320 x 240 pixels, touch screen with
127.5 mm x 170 mm active area
Operating and display elements 22 buttons, 1 key switch, 11 LEDs, 1 reboot button
Interfaces CAN1, CAN2, Ethernet 100BaseTX, USB (max. 3 m cable
length), RS232 (max. 3 m cable length)
Signal inputs IN1/IN2
Permissible length of CAN cable
for system networking
L
max
= 1000 m, depending on configuration, cable type
and topology
Recommended cable type for
CAN connection
J-Y-ST/Y2x2x0.8
Power supply connections DC1 (power supply),
DC2 (redundant power supply)
Input voltage 11 V DC to 30 V DC, from FPA-5000 or FPP-5000
Maximum power supply line
resistance
18 Ω
Maximum current consumption – Standby mode: 130 mA at 24 V DC
– In case of alarm: 225 mA at 24 V DC
Permissible operating
temperature
-5 °C to 50 °C
Permissible storage temperature -20 °C to 70 °C
Housing material and color ABS plastic, light gray (similar to RAL 7035)
