Modular Fire Panel Installation | en 71
Bosch Sicherheitssysteme GmbH System Description F.01U.028.089 | 8.0 | 2011.07
4.4.3 FPO-5000-EB Earth Bar
The FPO-5000-EB Earth Bar is inserted in the FMH 0000 A Mounting Frame Medium in a
prefabricated bracket. It allows star grounding of a centrally positioned extension housing.
Figure 4.21 FPO-5000-EB installation
FPO-5000-EB
FMH 0000 A
∅ 4 x 12 mm PZ2
PZ2
2x
PZ2
