Bosch FPA-5000 System Description

156 en | Technical Data Modular Fire Panel
F.01U.028.089 | 8.0 | 2011.07 System Description Bosch Sicherheitssysteme GmbH
7.3.4 PRD 0004 A Panel Rail Long for 4 Modules
Installation of the panel rail is described in Section 4.7 Panel Rails, page 84.
7.3.5 FPO-5000-PSB1/FPO-5000-PSB-CH Power Supply Brackets
Installation of the devices is described in Section 4.5 Power Supply Brackets, page 72.
7.3.6 UPS 2416 A Universal Power Supply 24 V/6 A
Input voltage 24 V DC (20 V DC to 30 V DC)
Current consumption at
24 V DC
2.8 mA
Output voltage +5 V DC ± 4.5%/24VDC
Maximum input current 8 A at 24 V DC
Maximum output current 1 A at 5 V DC
Permissible operating
temperature
-5 °C to 50 °C
Permissible storage
temperature
-20 °C to 60 °C
Material and color ABS plastic (UL94 V-0), satin finish, anthracite, RAL 7016
Space required (H x W x D) approx. 146 x 396 x 35 mm
Weight approx. 280 g
Permissible operating
temperature
-5 °C to 50 °C
Permissible storage
temperature
-20 °C to 60 °C
Weight
– FPO-5000-PSB1 approx. 550 g
– FPO-5000-PSB-CH approx. 395 g
Material PA6 plastic, Grilon BS V0 (UL94 V-0)
Color satin finish, anthracite, RAL 7016
Input voltage range 100 V AC to 240 V AC
Input frequency 50 Hz to 60 Hz
Input current max. 1.95 A
Efficiency > 85 %
Back-up time >16 ms at 115 V AC
Output voltage 26 V DC to 29 V DC
Maximum output current 6 A
Maximum power 160 W (permanent)
Cooling Ventilation without ventilator
Safety standards IEC 60950/EN 60950
Permissible operating temperature -5 °C to 50 °C
Permissible storage temperature -20 °C to 60 °C
Housing material and color Aluminum, anodized, black satin finish

Bosch FPA-5000 Specifications

General

Max Number of Detectors per Loop	254
Display	LCD
Network Capability	Yes
Power Supply	24 V DC
Operating Temperature	-5°C to +50°C
Communication Ports	Ethernet
Humidity Range	95% non-condensing
